Description
Conical Dual Horn Antenna 15 dBi Typ. Gain, 1.5-20GHz Frequency Range
|
RM-CDPHA1520-15 |
||
|
Item |
Specification |
Units |
|
Frequency Range |
1.5-20 |
GHz |
|
Gain |
15 Typ. |
dBi |
|
VSWR |
1.5:1 |
|
|
Cross Polarization |
35 |
dB |
|
3dB Beamwidth |
E-Plane:30 Typ, H-Plane:28 Typ. |
|
|
Polarization |
Dual |
|
|
Connector |
SMA-Female |
|
|
Finishing |
Paint |
|
|
Material |
Al |
|
|
Average Power |
50 |
W |
|
Peak Power |
100 |
W |
|
Size(L*W*H) |
253*Φ124.1 (±5) |
mm |
|
Weight |
0.496 |
kg |
Outline Drawing
Simulated Results
Gain
Cross Polarization
